Provides 3,000 W rated pure sine wave output with 6,000 W listed peak power for short startup demand.
Off-Grid Inverters
3,000 W Pure Sine Wave Power Inverter with UPS Charging
OEM supply inquiryVolume-order inquiry
Source a 3,000 W pure sine wave DC-to-AC inverter with 6,000 W listed peak output, integrated battery charging, and separate voltage and frequency versions for mobile and backup-power projects.
Provides 3,000 W rated pure sine wave output with 6,000 W listed peak power for short startup demand.
Source material lists separate 12 V or 24 V DC input versions and 110 V or 220 V AC output versions; confirm the required configuration before ordering.
Lists 90% efficiency, 50 Hz or 60 Hz output versions, and a maximum battery-charging current of 25 A.
Request a quotation
Ask about MOQ, lead time, market versions, packaging, and available OEM options.
Review the model-specific details.
Compare the listed electrical, mechanical, protection, and integration information before selecting a configuration.
DC-to-AC power inverters for battery-based mobile, field and backup-power applications.
Source material lists separate 12 V or 24 V DC input versions and 110 V or 220 V AC output versions; confirm the required configuration before ordering.
Lists 90% efficiency, 50 Hz or 60 Hz output versions, and a maximum battery-charging current of 25 A.
Listed protection functions include overcurrent, overvoltage, overload, overtemperature, short-circuit, and low-voltage protection.
Model specifications
Technical specifications
Compare electrical, mechanical, operating, and model-specific parameters for the available configurations.
Match the model and market version to the required system configuration before ordering.
Swipe horizontally to compare every model column.
| Parameter | 3,000 W configuration |
|---|---|
| AC output | |
| Rated output power | 3,000 W |
| Listed peak output power | 6,000 W |
| Output waveform | Pure sine wave |
| Listed efficiency | 90% |
| Electrical versions | |
| Battery input version | 12 V DC or 24 V DC; separate versions, confirm before ordering |
| AC output version | 110 V AC or 220 V AC, ±10%; separate market versions |
| Output frequency version | 50 Hz or 60 Hz; source states ±3 Hz |
| Maximum charging current | 25 A |
| Protection and mechanical data | |
| Listed protection functions | Overcurrent, overvoltage, overload, overtemperature, short-circuit, and low-voltage protection |
| Cooling | Dual-fan cooling |
| Dimensions (L×W×H) | 410 × 180 × 140 mm |
Select with the complete system in mind.
Start with the application, then confirm electrical fit, environment and order requirements against the selected model.
Size the expected loads
Compare continuous demand and short startup loads with the stated rated and peak output before selecting this configuration.
Confirm the battery version
Treat 12 V and 24 V DC input as separate order configurations, then confirm battery capacity, polarity and current capability for the selected system.
Confirm the market version
Specify the required 110 V or 220 V AC output and 50 Hz or 60 Hz frequency in the quotation before approval.
Plan a safe installation
Have a qualified installer confirm conductor sizing, protective devices, mounting, ventilation clearances and local electrical requirements.
Confirm the full system, not one feature
The listed power, efficiency, charging current and protection functions come from the supplied product material. Confirm the ordered voltage and frequency version, load compatibility, charging behavior, protective devices, ventilation and local requirements before approval.
Ask which current datasheet, user manual, packing list and market-specific order documents apply to the exact quoted configuration.
Discuss the required market configuration.
Use the inquiry to discuss available electrical configurations, branding, packaging, documentation, and project requirements.
Configuration options
Use the inquiry to discuss available electrical configurations, branding, packaging, documentation, and project requirements.
Commercial planning
Confirm quantity, lead time, destination market, and documentation.
