10.24 kWh and 15.36 kWh capacity in 200 Ah and 300 Ah versions.
Energy Storage Products
Floor-Standing Lithium Battery
OEM supply inquiryVolume-order inquiry
Compare AMPEXE floor-standing lithium battery systems for solar energy storage, backup power, and OEM applications.
10.24 kWh and 15.36 kWh capacity in 200 Ah and 300 Ah versions.
Maximum charge and discharge current is 150 A or 200 A, depending on the model.
Parallel connection of 1 to 15 compatible batteries is listed; confirm the final system design.
Request a quotation
Ask about MOQ, lead time, market versions, packaging, and available OEM options.
Review the model-specific details.
Compare the listed electrical, mechanical, protection, and integration information before selecting a configuration.
LiFePO4 battery ranges and compact energy storage systems for residential backup, solar storage, and OEM projects.
Maximum charge and discharge current is 150 A or 200 A, depending on the model.
Parallel connection of 1 to 15 compatible batteries is listed; confirm the final system design.
CAN, RS485, and RS232 communication interfaces are listed.
Model specifications
Technical specifications
Compare electrical, mechanical, operating, and model-specific parameters for the available configurations.
Match the model and market version to the required system configuration before ordering.
Swipe horizontally to compare every model column.
| Model | DX-48200BFSLB | DX-48300BFSLB |
|---|---|---|
| Total Energy (kWh) | 10.24 | 15.36 |
| Rated Capacity (Ah) | 200 | 300 |
| Nominal Voltage (V) | 51.2 | 51.2 |
| Float Voltage (V) | 56 | 56 |
| Equalization Voltage (V) | 57.6 | 57.6 |
| Discharge Cutting Voltage (V) | 44.8 | 44.8 |
| MAX Charge Current (A) | 150 | 200 |
| MAX C Rating | 0.6 C | 0.6 C |
| Dimension (mm) | 680*420*250 | 420*250*820 |
| Net Weight (kg) | 87 | 109 |
| Gross Weight (kg) | 100 | 122 |
| Scalable | 1-15 parallel | |
| Communication Ports | CAN, RS485, RS232 | |
| Cycle Life | ≥6000 cycles at 25 °C and 80% DoD; confirm test method | |
| Listed Compliance Documents | CE declaration, UN 38.3 test summary, and SDS/MSDS; confirm model-specific availability with AMPEXE | |
Select with the complete system in mind.
Start with the application, then confirm electrical fit, environment and order requirements against the selected model.
Set the storage target
Choose the stated capacity and format that fit the planned solar, backup or storage application.
Verify electrical limits
Confirm system voltage, charge and discharge current, and inverter compatibility before selection.
Plan mounting and expansion
Review the stated mounting format and parallel support against the available space and future capacity plan.
Confirm communications
Match the available BMS and communication interfaces to the intended inverter or energy management system.
Confirm the full system, not one feature
The listed BMS, breaker, environmental and thermal protection features apply within stated product limits. Confirm inverter compatibility, current limits, communications, installation conditions and local requirements.
Ask which current datasheet, user manual, packing list and market-specific order documents apply to the exact quoted configuration.
Scalable floor-standing storage
Available in 10.24 kWh and 15.36 kWh versions, with listed parallel expansion and communication options for system planning.
Residential solar storage
A floor-standing format for residential solar energy storage system planning.
Backup energy storage
High-capacity versions support dependable backup energy storage requirements.
Expandable OEM systems
Confirm parallel compatibility and communication requirements for the selected OEM configuration.
Product gallery
Review the available product views, enclosure details, controls, and installation format.
Discuss the required market configuration.
Use the inquiry to discuss available electrical configurations, branding, packaging, documentation, and project requirements.
Configuration options
Ask which branding, interface, enclosure, and packaging options are available.
Commercial planning
Confirm quantity, lead time, destination market, and documentation.
